Neutra
Lorem ipsum dolor sit amet, consectetur adipisicing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo the new normal in tungsten grinding.
Highlights
- Sealed grinding chamber with dust collector to protect the user
- Variable angle setting gives more flexibility
- Wet grinding prevents overheating of the electrode during grinding
- High grinding speed provides faster grinding and a smooth surface
- The electrode holder ensures centring of the tip and reduces wastage
- Less electrode wastage results in a short payback time
Descripción
Portable grinding machine for tungsten electrodes
Effective
NEUTRIX is a handheld and portable grinding machine that fulfills the equirements for safe and environmentally friendly grinding of Tungsten electrodes in high quality for TIG and plasma welding. Grinding in the longitudinal direction of the electrode, variable grinding angle, three grinding positions on the diamond disc and the electrode holder ensure efficient grinding.
Mobile and safe
The storage case and low weight make NEUTRIX ideal where there is a need to take the grinder with you. At the same time, the NEUTRIX, is equipped with an integrated dust filter that protects against the harmful grinding dust and collects the dust for safe disposal.
Short electrodes
NEUTRIX can grind electrodes down to lengths of 19 mm and even 15 mm with a special clamp, for example for orbital welding. The inspection cover on the grinder makes it easy to follow the grinding process and to ensure that the electrode is not generating sparks during grinding. This avoids the electrode being damaged by high temperatures.
Simple operation
Insert the electrode in electrode holder and lock it in the stick-out. Set the variable degree scale at the desired angle. Place the electrode holder in the grinder. Start the grinder and rotate the holder until it reaches the stop and the grinding isfinished.
Especificaciones
Grinder facts
Electrode size: Ø0.8 – 4 mm
Min. length: 19 mm standard (15 mm with special electrode clamps)
Angles: 7.5° – 90° grinding angle (equal to 15° – 180° tip angle)
Technical specifications
Motor: 110V-50/60 Hz, 220V-50/60Hz
Motor effect: 850W
Weight: 2.8 kg
Speed: 22,000 – 28,000 rpm
Grinding speed: 28 – 50 m/sec.
Standard unit includes
- Complete grinder with diamond disc, filter and storage case
- Electrode holder
- Electrode clamps for Ø1.6, 2.4 and 3.2 mm electrodes (clamps are available for other electrode sizes)
Extra accesories
- Foot for mounting on a work table
- Electrode clamps for all electrodes from Ø0.8 – 4.0 mm
- Electrode clamps for grinding extra short electrodes
Add-ons & parts
Lorem ipsum dolor sit amet, consectetur adipisicing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.
Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.
Book a free demo
Our tungsten grinders reduces the use of tungsten electrodes by up to 50%. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.
TIG welding applications
Lorem ipsum dolor sit amet, consectetur adipisicing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Used for more than 30 years
35,000+ units sold
Used in numerous sectors
